Tweak 12 LED Downlight, CCT
DATASHEET - 12W TWEAK CCT LED Downlight, Dimmable, 190mm/145mm
www.lumeno.ie
LM-RDT12
Tweak 12 LED Downlight, CCT
D
1263LM
CCT Selectable Downlight
Dimmable with trailing-edge dimmers
IP44 ingress protection
CCT Selectable recessed downlight dimmable with universal dimmer types. Diffused light output.
Technical Specifications
General
Model
LM-RDT12
Product type
Recessed Light
Warranty
3 Years
Accessories
2x 3-wire wago Joiners,
Product finish
White
Electrical
Input Voltage (Pri)
220V - 240V AC
Nominal Power
12 Watt
Dimming / control type
Phase-cut
Lighting
Luminaire classification
MDLS
Light source
LED
Luminous flux (lm)
1263LM
Luminous efficacy (lm/W)
135
Colour rendering index (CRI)
>RA85
Beam angle (degrees)
>100°
Mechanical
Rated lifetime (hours)
30000h
IP rating
IP44
Dimensions (mm)
Ø190 x 82mm
Cutout dimensions (mm)
Ø145mm
