DATASHEET - Dotless LED Strip Series

www.lumeno.ie
SmartCut 2M, Cob320, 5W/M, IP55, 24V, W/White
SmartCut 2M, Cob320, 5W/M, IP55, 24V, W/WhiteSmartCut 2M, Cob320, 5W/M, IP55, 24V, W/White
LM-STC320WW-2M5

SmartCut 2M, Cob320, 5W/M, IP55, 24V, W/White

No vote
520.47LM
  • SmartCut IP55, 2000mm with connection wire
  • 24V DC Input Voltage
  • Minimum Cut : 50mm
  • Efficacy up to 115 LM/W
  • Single bin LED selection to ensure color consistency
  • Fully dimmable with PWM output drivers.
  • Thermally conductive RED 3M VHB adhesive
  • Applications: near reflective surfaces, direct visibility installations
SmartCuts™ pre-assembled piece for quick installation. COB320 Slick series represents a cutting-edge advancement in LED lighting technology, adopting luminous silicon design for dotless lighting effect. COB strips deliver higher brightness and improved thermal management compared to traditional LED strips wattage equivalents. With their slick compact form and efficient light output, COB Strip series are ideal for applications requiring high illumination levels and discreet lighting effect.

Technical Specification

ModelLM-STC320WW-2M5
Luminare Class NMDLS
Light Source LED
Luminous Flux (LM) 520.47LM
Nominal Power 5 Watt
Correlated Colour Temperature (CCT) 2700K
Colour Rendering Index (CRi) 91.4
Input Voltage (Pri) 24V DC
Min Cut (Circuit) 50mm (3 LED)
Product finish White PCB
Lifespan 50Kh
Ingress Protection IP55
Dimming PMA
Size 2000 x 8mm x 2mm
Warranty Period 3 Years
Maximum Length (mm) 10000
Connection Wire 2 Core - 20AWG
