LM-CT2802BEA-RJ45
DMX Decoder, RJ45, 4x8A 12V-36V
- Constant voltage DMX512 decoder with 3 channel or 4 channel selectable
- Three-channel / Four-channel output selectable
- RJ 45 and terminal block for DMX Connection
- 8A per channel :12VDC/24VDC/36VDC output
High capacity DMX Decoder for LED strip lights.Can be set to work as a 3ch or 4ch decoder @ 8A each (x4 12V@96W, 24V@192W). Digital display for address and mode setting. Terminal block connector and RJ45 interface. Max 30 devices can work in one DMX universe.
Technical Specification |
| Model | LM-CT2802BEA-RJ45 |
|
Input Voltage (Pri)
|
12V-36V DC
|
|
Output
|
RGBW+
|
|
Current Output (Io)
|
4Ch, 8A/Ch
|
|
Ingress Protection
|
IP20
|
|
Working Temperature
|
-30°C ~+55°C
|
|
Certification
|
CE ROHS Certified
|
|
Warranty Period
|
3 Years
|
