LM-STC504-NW

COB LED Strip, 504 chips/m,12V,10W,18mm cut,10mm FPC,4000K

No vote
863LM
  • Extra small cutting sections 20mm
  • COB LED, 504 LEDS Coated
  • 12V DC, 10 Watt / m
  • Custom cuts
  • Non-Waterproof IP20 for indoor only
  • Self-adhesive back - RED 3M tape

COB Solution. 504 small LED chips per meter coated with light enhancing plastic. No-dot solution for exposed areas. Natural White 4000K for general applications.

Technical Specification

ModelLM-STC504-NW
Luminous Flux (LM) 863LM
Nominal Power 10 Watt
Correlated Colour Temperature (CCT) 4000K
Colour Rendering Index (CRi) >90
LED Quantity 504LED / M
LED Type COB
Input Voltage (Pri) 12V DC
Min Cut (Circuit) 20mm (COB)
Output (Vo) 12V DC
FPC Size 3Oz FPC, 10mm
Ingress Protection IP20
Warranty Period 5 Year
Maximum Length (mm) 5000
Connection Wire 2 Core - 20AWG
