Edge'18W PIR CCT Selectable Multi Wattage Downlight
DATASHEET
www.lumeno.ie
LM-RDS18M
Edge'18W PIR CCT Selectable Multi Wattage Downlight
No vote
E
1822LM
Rimless solution, full lighting face
Wattage Adjustable: 8W-18W
5 CCT Selectable: 2700-3000-3500-4000-5000K
IP54 Standard, IP65 with installation base
Motion Detection: Day-time/Nightime
Modern Design
Edge Series CCT & wattage selectable round LED Lights are a sleek, modern fixtures designed for versatile ceiling or wall installation.
Technical Specification
Model
LM-RDS18M
Luminare Class
MDLS
Light Source
LED
Luminous Flux (LM)
1822LM
Luminaire efficacy
104
Nominal Power
18 Watt
Available Flux
1822
Colour Rendering Index (CRi)
CRi>80
LED Type
SMD 2835
Light Angle (°)
110°
IK Rating
IK04
Lifespan
30K Hours
Dimming
8W-18W Selectable
Size
Ø230mm x 39mm
Weight
565g
Accessories
*Installation base
Certification
CE Rohs
Warranty Period
3 Years
