24V 35W, Power Supply, n/d, IP20, plastic, terminals
DATASHEET - IP40 Class II Power Supply
www.lumeno.ie
LM-PS24V35PC
24V 35W, Power Supply, n/d, IP20, plastic, terminals
Single channel constant voltage output
Plastic housing and class II design without FG
Universal AC input / Full range
100% full load burn-in test
No load power consumption<0.5W
High efficiency, long life and high reliability
Compact, plastic case power supply with 5mm terminal blocks.
Technical Specifications
General
Model
LM-PS24V35PC
Product type
Power Supply (CV)
Compliance summary
CE ROHS Certified
Warranty
1 Year
Electrical
Input Voltage (Pri)
110V - 240V AC
Rated output power (W)
35 Watt
Rated output current (A / mA)
1.46A
Dimming / control type
non-dimmable
Power factor
0.95
Inrush current
50A typ. @ 230Vac
Standby power (W)
<0.5W
Lighting
Output specification
24V DC
Mechanical
IP rating
IP20
Dimensions (mm)
145*33.5*22mm
Weight
75g
Operating temperature (degrees C)
-20°C ~ 60°C
