DATASHEET - 40W CCT LED Wall Light, SON/WW/NW, VANTAGE

www.lumeno.ie
vantage-1
vantage-1vantage-2vantage-3vantage60-4
LM-MWV40CCT

Vantage 40 CCT External Wall Pack

5 5 1 Product


D

5178LM
  • EPISTAR 2835 Matrix as light source
  • Compact modern design,
  • Integrated, detachable Photocell sensor
  • CCT Selectable light output 2000K - 3000K- 4000K
  • IP65 Waterproof complete with Rubber grommets
  • Isolated driver - no power leak via sensor
  • Beam Angle of over 100°

VANTAGE LED Wall Light series is a modern design of an external wall-pack light. Using high quality SMD2835 chips providing 3 distinct colour temperatures all in one luminaire.

Technical Specification

ModelLM-MWV40CCT
Luminare Class MDLS
Light Source LED
Luminous Flux (LM) 5178LM
Luminaire efficacy 152
Nominal Power 40 Watt
Input Voltage (Pri) 110V - 240V AC
Power Factor 0.98
Light Angle (°) 90°
Product finish Carbon Gray
Ingress Protection IP65
Warranty Period 3 Years
